A: Ensure loop is held directly beside transceiver for pairing process, initiate code process on transceiver, this should automatically detect loop and successfully pair if close enough. For commercial or inground loops: these can be paired in close proximity or in location by using pairing method 2.

(See video linked below.)
https://youtu.be/3FcmmoQKl2Q?t=23

A: The loop can be placed up to 50M away from the transceiver using supplied antenna, ensure a clear line of sight between loop & transceiver. Please note: housing the transceiver in a metal enclosure or close to high voltage power lines could reduce the transmission range. If you are having issues, please try house the transceiver in its own separate enclosure or try an external antenna.

A: A. Press and hold the code button for approx. 11 seconds until you see all 3 LED’s on transceiver flash up. This will clear the memory of the transceiver, you can then go ahead and start the pairing/coding process with your loop/s.

(See video linked below.)
https://youtu.be/wPtsT1zbzAU

A: The loop has a detection area of 1.5M (radial) distance from the centre of loop. By default, our loops are setup in a way that they will detect almost any vehicle as it passes directly over the loop. If you feel the loop is too sensitive and picking up smaller objects other than vehicles it may be worth trying to recalibrate the loop firstly. If still having issues, please call technical support to discuss. +44 28 8639 0693  We also offer the e-Diagnostic remote which allows you fine tune loop settings.

(See video linked below.)
https://youtu.be/rEBzsZNDAJg

A: Test by placing metal object or driving vehicle over loop, on the transceiver check if Red/RX LED comes on while doing so, this will indicate the loop is triggering and signal sent to transceiver firstly. If gate is not triggering, double check wiring from gate motor, you can also test & prove relay is changing state by using a multi-meter. If still having issues, please call technical support to discuss further. +44 28 8639 0693 

A: Yes you can pair up to 4x loops to either e-Trans 50 or e-Trans 200. This can be any variety of loops; exit mode, presence mode, commercial or residential.
